Angiographic and Histologic Analysis of Experimental Aneurysms Embolized with Platinum Coils, Matrix, and HydroCoil

Methods

Elastase-induced, saccular aneurysms were created in 33 New Zealand white rabbits. The institutional animal care and use committee at our institution approved all procedures. Following aneurysm creation, at least 21 days elapsed before embolization, as previous studies have recommended (19). Embolization was performed with HydroCoil (n = 9), Matrix (n = 15), or platinum coil (n = 9) devices. After embolization, subjects were followed for 2 weeks (n = 11), 6 weeks (n = 11), and 10 weeks (n = 11).

Aneurysm Creation

Detailed procedures for aneurysm creation have been described elsewhere (18). In brief, anesthesia was induced with an intramuscular injection of ketamine, xylazine, and acepromazine (75 mg/kg, 5 mg/kg, and 1 mg/kg, respectively). By using a sterile technique, the right common carotid artery (RCCA) was exposed and ligated distally. A 1–2-mm beveled arteriotomy was made and a 5F vascular sheath (Cordis Endovascular, Miami Lakes, FL) was advanced retrograde in the RCCA to a point approximately 3 cm cephalad to the origin of RCCA. A roadmap image was obtained by injection of contrast through the sheath retrograde in the RCCA, to identify the junction between the RCCA and the subclavian and brachiocephalic arteries (Advantx; General Electric Company; Milwaukee, WI). A 3F Fogarty balloon (Baxter Healthcare, Irvine, CA) was advanced through the sheath to the level of the origin of the RCCA with fluoroscopic guidance and was inflated with iodinated contrast material. Porcine elastase (5.23 μ/mgP, 40.1 mgP/mL, approximately 200 U/mL; Worthington Biochemical, Lakewood, NJ) was incubated within the lumen of the common carotid above the inflated balloon for 20 minutes, after which the catheter, balloon, and sheath were removed, the RCCA was ligated below the sheath entry site.

Description of Embolic Devices

Embolization Procedures

Five aneurysms were used at each time point (2, 6, and 10 weeks) for the Matrix group, whereas three aneurysms were used at each time point for the HydroCoil and platinum coil groups. Previous work in the rabbit elastase model demonstrated consistent angiographic and histologic results of HydroCoil and platinum coil–treated aneurysms (7, 16). Thus, a lower number of replicates was selected for the HydroCoil and platinum coil groups. In the same work, thrombus organization was shown to be incomplete at 2 weeks, mostly complete at 6 weeks, and complete at 13 weeks. In this study, the 2-week time point was selected to evaluate incomplete organization, whereas the 6- and 10-week time points were selected to evaluate complete organization and the stability of the response.

Details about the embolization procedure have been described elsewhere (11, 16). In brief, anesthesia was induced and maintained as during aneurysm creation. Using a sterile technique, surgical exposure of the right common femoral artery (CFA) was performed and a 5F vascular sheath was placed. Heparin (100 U/kg) was administered intravenously. A 5F catheter (Envoy; Cordis Endovascular) was advanced into the descending aorta. Placement of the guiding catheter in this position results in the microcatheter being relatively poorly supported. We chose this guiding catheter position to simulate the clinical scenario, because modified coil devices may suffer from inferior handling characteristics compared with platinum coils. By using a coaxial technique, a microcatheter (Excelsior 10–18, Boston Scientific) was advanced into the aneurysm. The size of the aneurysm was assessed by direct comparison with radiopaque sizing devices.

Theoretical volumetric occlusion was estimated based on volume of the aneurysm and volume of implanted devices. For these calculations, the aneurysm dome and length, as well as a radiopaque calibration marker, were measured by using a ruler. The volumes of the aneurysms were determined from the dome and length measurements of the aneurysms before embolization. The aneurysms were assumed to be cylindrical and the volume was determined from the equation

The volumes of the devices were determined by ex vivo measurement. Theoretical volumetric occlusion was determined by taking the sum of the volume of all the devices implanted divided by aneurysm volume.

Embolization was performed in aneurysms by use of either the HydroCoil, platinum coils, or Matrix, as done clinically and according to a randomized schedule. For the platinum coil group, the aneurysm was framed with a single complex coil, embolized by complex and helical coils as densely as possible. Aneurysms in the HydroCoil group were framed with a single platinum complex coil, followed by packing with HydroCoil devices as densely as possible. The Matrix group aneurysms were packed with 2D Matrix coils. The framing and packing strategy was selected to mimic the clinical use of the embolic devices. Efforts were made to avoid protrusion into parent artery in all groups. The total length of devices, number of devices, and procedure time were recorded for each embolization. After embolization, the catheters were removed. The vascular sheath was removed, and the proximal aspect of the femoral artery was ligated with a 4-0 silk suture.

Follow-Up Procedures

Follow-up imaging evaluation and tissue harvest were performed. Subjects euthanized at 2, 6, and 10 weeks underwent intra-arterial digital subtraction angiography (IADSA) at the time of sacrifice. On the day of sacrifice, surgical access of the left CFA was achieved, in similar fashion to that used for access of the right CFA described above. A 5F catheter was placed in the aortic arch, and DSA was performed. Immediately following angiography, the subjects were euthanized by a lethal injection of pentobarbital. The mediastinum was dissected, and the aortic arch and proximal great vessels, including the coil-embolized segment of artery, were exposed and dissected free from surrounding tissues. The tissue was immediately placed in 10% neutral buffered formalin.

Histologic Processing

Three aneurysms from the HydroCoil and Matrix groups at each time point were embedded in methyl methacrylate, sectioned with a diamond saw, and surface-stained with hematoxylin and eosin. The aneurysms from the platinum coil group, as well as two aneurysms from the Matrix group, at each time point were embedded in paraffin. Sections, approximately 1 mm thick, were prepared with a saw. The coils were removed from the sections by hand. The section was re-embedded in paraffin wax, sectioned at 5–10 μ, and stained with hematoxylin and eosin.

Evaluation Criteria

Statistical Analysis

All statistical analyses were performed by using JMP software (SAS Institute, Cary, NC). Statistically significant differences in normally distributed data were determined by using an ANOVA test. Statistically significant differences in discrete data were determined by using a χ² test. In all cases, statistical significance was accepted at α ≤ 0.05.

Results

Procedural Results

Aneurysms were successfully embolized in all 33 cases without acute or chronic morbidity or mortality. Results are summarized in Tables 1 and 2. Statistically significant differences among groups regarding aneurysm size (neck, width, and height), total device length, and procedure time were not present. There were, however, significant differences among the number of devices utilized between three groups. The number of devices implanted in the Matrix group was significantly less than platinum coil (P = .02) and HydroCoil groups (P = .03). Premature detachment occurred in one Matrix coil when we tried to advance it into an aneurysm. Premature detachment did not occur with other devices.

View this table:

• View inline
• View popup

TABLE 1:

Pooled aneurysm data

View this table:

• View inline
• View popup

TABLE 2:

Pooled embolization results

Statistically significant differences in the volumetric filling of the aneurysms were present. The volumetric filling of HydroCoil-treated aneurysms (76% ± 32%) was significantly greater than those treated with platinum coils (31% ± 9%; P < .0001) or Matrix coils (23% ± 7%; P < .0001)

Angiography.

Angiographic occlusion scores (complete occlusion/near-complete occlusion/incomplete occlusion) immediately following embolization were 4/5/0, 6/6/3, and 5/3/1 for platinum coils, Matrix coils, and HydroCoil, respectively. At follow-up, angiographic occlusion scores were 4/5/0, 8/2/5, and 8/1/0 for platinum coils, Matrix coils, and HydroCoil, respectively. Follow-up angiographic durability scores (progressive occlusion/stable occlusion/recurrence) were 1/6/2, 2/8/5, and 4/5/0 for platinum coils, Matrix coils, and HydroCoil, respectively (Figs 1–3). There were no cases of delayed, progressive compromise of the parent artery.

• Download figure
• Open in new tab
• Download powerpoint

Fig 1.

Number 3 aneurysm in Matrix group, 2-week implant.

A, Anteroposterior DSA of the brachiocephalic artery shows a moderately wide-necked aneurysm.

B, Anteroposterior DSA obtained immediately after embolization with Matrix coils shows near-complete occlusion of the aneurysm.

C, Anteroposterior DSA obtained 2 weeks after embolization shows marked coil compaction.

D, Hematoxylin and eosin stain; original magnification, ×1.5. Coronal section obtained through the aneurysm cavity. Microcompaction and inflammation along neck are shown.

E, Hematoxylin and eosin stain; original magnification, ×25. Magnification of the area shown in panel D; substantial inflammation is shown along neck.

• Download figure
• Open in new tab
• Download powerpoint

Fig 2.

Number 9 aneurysm in Matrix group, 10-week implant.

A, Anteroposterior DSA of the brachiocephalic artery shows a wide-necked aneurysm.

B, Anteroposterior DSA obtained immediately after embolization with Matrix coils shows the aneurysm is nearly completely occluded.

C, Anteroposterior DSA obtained 2 weeks after embolization shows slight coil compaction.

D, Hematoxylin and eosin stain; original magnification, ×1.3. Coronal section obtained through the aneurysm cavity. Marked microcompaction and unorganized thrombus are shown. There is no tissue across the aneurysm neck.

E, Hematoxylin and eosin stain; original magnification, ×25. Magnification of the area shown in panel D. Dense cellular infiltration near coils in the dome is seen.

• Download figure
• Open in new tab
• Download powerpoint

Fig 3.

Number 15 aneurysm in HydroCoil group, 6-week implant.

A, Anteroposterior DSA of the brachiocephalic artery shows a wide-necked aneurysm.

B, Anteroposterior DSA obtained immediately after embolization with HydroCoils shows the aneurysm is nearly completely occluded.

C, Anteroposterior DSA obtained 2 weeks after embolization shows the aneurysm remaining stable.

D, Hematoxylin and eosin stain; original magnification, ×1.1. Coronal section obtained through the aneurysm cavity. No substantial inflammatory response is present. Microcompaction is absent. A small part of persistent unorganized thrombus is shown in the aneurysm dome.

E, Hematoxylin and eosin stain; original magnification, ×10. Magnification of the area shown in panel D. Cellular fibrous tissue is shown across the neck.

Discussion

In this study, we carried out a direct comparison among platinum coils, Matrix coils, and HydroCoils in the rabbit, elastase-induced aneurysm model, to gain improved understanding of the healing mechanisms of these three devices. We demonstrated that enhanced tissue response, as compared with platinum coils, is reliably achieved with the Matrix coil in this animal model. Even with this enhanced tissue response, however, angiographic outcome was not improved by the Matrix device compared with platinum coils. Indeed, even in cases of marked inflammatory response with Matrix, substantial coil compaction was observed. Conversely, the HydroCoil allowed significant increases in filling volume as compared with other coils and also achieved improved coil stability, on both angiographic and histologic analysis.

We believe that these results offer insights into important mechanisms behind the failure of coils in saccular aneurysms. Our findings indicate that biologic modification alone, without mechanical stability, may fail to improve coil performance. Structural modification, aimed at improving the mechanical stability of the device at the aneurysm neck, may offer a more promising approach to coil design than biologic modifiers. Indeed, from a clinical standpoint, angiographic recanalization is considered a failure, regardless of improved tissue reaction around coils.

Expandible HydroCoils have been shown to fill significantly more volume than nonexpandible platinum coils in both clinical and preclinical studies (32). Histologic study at all time points after embolization showed only small amounts of unorganized thrombus or tissue within aneurysm cavities, with most of the aneurysm cavity filled with expanded hydrogel. Long-term aneurysm occlusion with the HydroCoil device is not dependent on stimulation of host reaction to the implant. Instead, occlusion is achieved by filling of the aneurysm with the biomaterial itself (16). Further, the expanded hydrogel excludes thrombus from the aneurysm cavity, eradicating the tendency for aneurysm regrowth from thrombus resorption or recanalization.

Previous results from the swine aneurysm model showed Matrix accelerates clot organization (13, 15). More organized thrombus, thicker neointima, and neoendothelial coverage of the neck of experimental aneurysms embolized by Matrix in swine were noted within 14 days, as compared with platinum coil (15). In our study using elastase-induced model in rabbits, the occurrence of strong tissue reaction in the Matrix group was higher than that of the HydroCoil and platinum coil groups. Unlike the swine sidewall model, however, coil compaction was commonly seen with Matrix coils in the model used in this study. The rabbit elastase aneurysm is subjected to considerably more hemodynamic stress than the swine sidewall aneurysm, which possibly explains the presence of compaction seen in the rabbit elastase aneurysm and the lack thereof in the swine sidewall aneurysm. Additional clinical data are necessary to assess which of these two models better predicts clinical outcome.

Two variations between groups were present in this study—namely, in the method of embolization and method of histologic processing. The HydroCoil and platinum coil groups were embolized first with a platinum coil. The Matrix group was embolized first with a Matrix coil. This variation was selected to represent the usual clinical practice of the device. We believe that this variation did not affect the outcome of the results. Second, we chose methyl methacrylate embedding for the HydroCoil and Matrix groups and paraffin embedding for the platinum coil group. The choice of methyl methacrylate embedding for HydroCoil and Matrix groups was made on the basis of prior experience of the industry sponsor of this project. Paraffin embedding, a technique still in development, was used for the platinum coils not only to further the development of the technique, but also to achieve efficiency of animal use. It is possible that some difference in histologic outcome may result from differences in processing, but we are not aware of any systematic difference that would have affected the results.

This study, though offering notable findings that may predict the clinical response, had limitations. The number of subjects in each group was small. This limitation is somewhat offset by the finding of relative concordance within each group, which suggests that even more subjects may not have changed outcome. Also, the sizes and neck breadth were variable, and this may have affected outcome in selected cases. Further, there remains no robust histologic grading system that has been shown to predict clinical outcome for any animal model of aneurysms.

We chose to use both angiographic evidence of compaction as well as histologic evidence of compaction in this study. Marked compaction that is evident on histologic sections may be unapparent on angiography (33). This occurs in the setting of a concave, central compaction occurs that may be masked on angiography by the coils remaining in the periphery of the neck.

Conclusions

The use of HydroCoil results in improved long-term occlusion rates compared with Matrix and platinum coils. The Matrix group showed an increase in inflammation and coil compaction compared with HydroCoil and platinum coils.
